Features & Benefits
- Accept standard IEC motors
- Universal mounting
- Thickened size and performance gradation
- High, reliable and tested performance (Ni bronze); optimization of worm gear pair performances (ZI involute profile and adequately conjugate worm wheel profile)
- Compactness, standardized dimensions and compliance with standards
- Rigid and precise cast iron monolithic casing
- Generous internal space between train of gears and casing allowing high oil capacity, lower oil pollution, greater duration of worm wheel and worm bearings, and lower running temperature
- Possibility of fitting particularly powerful motors and transmitting high nominal and maximum torques
- High manufacturing quality standard
- Possibility of obtaining multiple drives and at synchronous speed
- Wide design and accessory availability
- Reduced maintenance
Technical Specifications
| Unit Sizes | 01, 02, 03, 04, 05, 06, 07, 08, 09, 10, 11, 12, 13, 14 |
| Input Power | Up to 7.5 kW |
| Output Torque | Up to 1,900 Nm |
| Gear Ratios | 10:1 to 315:1 |
| Motor Sizes | IEC Frames from 63 to 200 |
